Buyer guide · Electronics & assembly

Laser soldering machine from China

Search for a laser soldering machine and most results are metal laser welders, which will burn a circuit board, so first make sure the quote is for a low-power soldering station with wire feed and temperature control.

Ask about this machine ↗Where the numbers come from

Written and listings checked 30 September 2026. Every figure on this page names its source.

What you are actually comparing.

Two quotes, one machine name

What hides inside the price

Soldering or welding source

Laser soldering uses a low-power diode laser to melt solder on the joint. Thirteen of fifteen listings we checked were fibre or YAG metal welders. Ask the laser type, wavelength and power range.

Temperature feedback

A pyrometer that reads the joint and controls laser power keeps boards from scorching. None of the fifteen listings mentioned it. Ask whether it is fitted.

Solder feed

Wire feed, paste dispensing or solder balls. Ask which wire diameters the feeder takes and how feed is synchronised with the laser.

Enclosure and laser class

A closed cabinet can bring the machine to Class 1 under EN 60825-1. An open station needs a laser area and eyewear. Ask the class on the label.

Before you ask for a price.

Send these with the enquiry. Without them, any number a factory gives you is a guess dressed as a quotation.

Joint drawings: pad size, component and solder alloy.
Board and nearby heat-sensitive parts.
Joints per product and products per shift.
Flux type and fume extraction available.
How parts are located: fixture or camera.

Turn the claim into a demonstration.

Require this	A pass looks like
Solder a counted batch of your joints with your wire.	Joints inspected against IPC-A-610 at your class, faults counted and recorded.
Log joint temperature by the pyrometer during the run.	Peak stays inside your alloy and component limits on every joint.
Open the cabinet door while the laser is firing.	The laser stops at once.

The documents that must arrive with it.

EU Declaration of Conformity citing 2006/42/EC, or Regulation (EU) 2023/1230 for delivery from 20 January 2027, Low Voltage 2014/35/EU, EMC 2014/30/EU, EN 60825-1 and EN ISO 11553.
Manual in your language with laser class, eyewear needs and service steps.
Laser module datasheet with serial number.

The one people forget. The eyewear specification for service work. Even a Class 1 cabinet exposes the beam when opened for service, and the manual must say which eyewear protects at that wavelength.

When this is the wrong machine.

Buy something else if

Named, not hedged

Your boards have many through-hole joints in a row.

A wave or selective soldering machine.

You join metal parts, not solder joints.

A laser welding machine, which is what most listings under this name actually are.

Where the numbers come from.

We name the kind of source, how many and when, and never the factory. Listed prices are asking prices, not landed cost. Where we do not hold a fact we say so: that is a GAP, not an estimate.

Listings · 15Fifteen marketplace listings for laser soldering machines, checked September 2026: thirteen were fibre or YAG metal laser welders and two were small jewellery laser units; none mentioned temperature feedback at the joint.
GAPGAP - no supplier quotations logged for this machine yet. Three to five quotations for one configuration would give a real price spread.
GAPGAP - no listing for an electronics laser soldering station with a price was found in this check. A targeted request to three makers would close it.

Related machines.

Battery spot welding machine. Choose a battery spot welding machine when you join nickel strip to cells rather than solder joints.
Ultrasonic plastic welder. Choose an ultrasonic plastic welder when the joint is plastic to plastic.

Every machine we source in this area is on the Electronics & assembly page. How a project runs, stage by stage, is on how it works, and what it costs is on pricing.

Straight answers

Questions buyers ask about this machine.

Chinese vs European laser soldering machine?+

The laser modules can be close. Temperature control and process software differ most; test those.

What goes on a laser soldering inspection checklist?+

The three tests above and the laser module serial against the invoice.

What CE documentation does it need?+

A Declaration of Conformity with the laser standards, a technical file and a manual in your language.

Who is the EU importer?+

Your business if it brings the machine in: your name and address go on it.
