Axes and head
Three axes engrave and cut flat; five tilt the tool for undercuts and sculpture.
No DramaBuyer guide · Construction
A light 3 axis engraving router and a heavy 5 axis centre for sinks and sculpture share one name, and choosing between them is the whole decision.

01
Three axes engrave and cut flat; five tilt the tool for undercuts and sculpture.
Listings state 3 to 10 kW. Ask how water reaches the tool, since stone is cut wet.
Welded tube frames suit engraving; granite needs mass. Ask the machine weight.
Routers state 150 to 400 mm; one 5 axis listing stated 1.0 m.
02
Codes such as 1325 give the working area in centimetres.
03
Send these with the enquiry. Without them, any number a factory gives you is a guess dressed as a quotation.
04
| Require this | A pass looks like |
|---|---|
| Machine your own drawing in your hardest stone. | Part inside the offer tolerance, with no chipped edges. |
| Run one hour at full load with water on. | Guides stay dry and spindle temperature stays stable. |
| Check travel on all axes. | Stated area and Z travel reached with a full length tool. |
05
06
A stone bridge saw, which cuts with a large blade far faster than a router tool.
A terrazzo tile machine.
07
We name the kind of source, how many and when, and never the factory. Listed prices are asking prices, not landed cost. Where we do not hold a fact we say so: that is a GAP, not an estimate.
08
Every machine we source in this area is on the Construction page. How a project runs, stage by stage, is on how it works, and what it costs is on pricing.
Straight answers
For engraving, Chinese routers are common. For 5 axis work a used European centre can be the better buy.
A test part in your stone, axis travel, slurry sealing and emergency stops.
A Declaration of Conformity with the serial number, and noise data in the instructions.
Usually your company, when you buy direct. Your name goes on the machine or its papers, and you check the conformity file.
