Buyer guide · Lab & process

Industrial centrifuge from China

Separation depends on g force and on your feed, yet two sellers can publish different speeds, g figures and flow rates for the same model code, and the flow is usually measured on water.

Ask about this machine ↗Where the numbers come from

Written and listings checked 30 September 2026. Every figure on this page names its source.

What you are actually comparing.

Two quotes, one machine name

What hides inside the price

Centrifuge type

Decanters discharge solids continuously with a screw. Disc stacks clarify liquids and split oil from water. Tubular bowls reach very high g for fine solids but are emptied by hand. Basket units filter crystals.

Bowl radius and speed

g force rises with radius and with speed squared. Ask for both, and the maximum speed at your feed density.

Rated flow and its test liquid

Flow figures are often water. Ask for flow at your solids content and target clarity.

Bowl material and balancing

Stainless grade of bowl and wetted parts, and a dynamic balancing report. An unbalanced bowl wears bearings fast.

Guarding and solvent service

Lid interlock, overspeed protection and vibration trip. For flammable solvents, an ATEX build or inert gas blanketing is a separate price.

Decode the model code.

In the GQ tubular series the number usually gives bowl inner diameter in millimetres. It is not a rule: one table lists the GQ150 with a 142 mm bowl. Read the table, then check the g figure against speed.

g = 0.00001118 x radius in cm x rpm squared.
GQ105: radius 5.25 cm. At 19,000 rpm: 0.00001118 x 5.25 x 19,000 x 19,000 = about 21,200 g.
At 16,300 rpm: 0.00001118 x 5.25 x 16,300 x 16,300 = about 15,600 g.

Before you ask for a price.

Send these with the enquiry. Without them, any number a factory gives you is a guess dressed as a quotation.

Feed composition: solids percent, particle size, densities of each phase and viscosity.
Two-phase or three-phase split, and which phase is the product.
Flow per hour on your feed, and continuous or batch operation.
Required clarity of the liquid and dryness of the solids.
Whether the feed contains a flammable solvent, and whether it touches food or medicine.

Turn the claim into a demonstration.

Require this	A pass looks like
Run your own feed at the quoted flow and speed, sampling liquid and solids outlets.	Solids in the clarified liquid and moisture in the cake both inside the values written into the order.
Measure vibration at full speed with the bowl loaded.	Vibration below the limit in the manual, with the balancing report matching the bowl serial number.
Try to start with the lid open, and trigger the overspeed trip, under factory supervision.	The machine refuses to start with the lid open and trips on overspeed.

The documents that must arrive with it.

EU Declaration of Conformity for the serial number: 2006/42/EC until 19 January 2027, then Regulation (EU) 2023/1230, plus 2014/35/EU and 2014/30/EU. Ask which harmonised standard for centrifuges was applied.
Material certificates for the bowl and wetted parts, and ATEX 2014/34/EU marking where solvent is present.
Manual with maximum speed against feed density and the bowl inspection interval.

The one people forget. The dynamic balancing report tied to the bowl serial number. Insurers and service engineers ask for it after the first bearing failure.

When this is the wrong machine.

Buy something else if

Named, not hedged

You need to remove a solvent from a dissolved product, not solids from a liquid.

A rotary evaporator, which separates by boiling under vacuum.

You spin samples in tubes for testing, not a process stream.

A benchtop laboratory centrifuge, which is a far smaller and simpler purchase.

Where the numbers come from.

We name the kind of source, how many and when, and never the factory. Listed prices are asking prices, not landed cost. Where we do not hold a fact we say so: that is a GAP, not an estimate.

Listings · 24Twenty-four priced marketplace listings for Chinese industrial centrifuges, checked September 2026, ran from US$4,800 for tubular units to US$138,900 for large three-phase machines. Asking prices, not landed cost.
Listings · 2Two spec tables for the GQ105 tubular centrifuge, checked September 2026, both gave a 105 mm bowl but stated 19,000 rpm and 21,000 g against 16,300 rpm and 15,620 g, with rated flow of 1,500 kg/h against 1,200 L/h.
Arithmetic0.00001118 x 5.25 x 19,000 squared = about 21,200 g. 0.00001118 x 5.25 x 16,300 squared = about 15,600 g.
GAPGAP - no supplier quotations logged for this machine yet. Three to five quotations for one configuration would give a real price spread.

Related machines.

Rotary evaporator. Look at a rotary evaporator when the job is solvent removal rather than solids separation.
Stainless steel reactor vessel. Look at a reactor vessel when you need to react or crystallise the batch before separating it.

Every machine we source in this area is on the Lab & process page. How a project runs, stage by stage, is on how it works, and what it costs is on pricing.

Straight answers

Questions buyers ask about this machine.

Chinese vs European industrial centrifuge: where does the money go?+

Bowl material and machining, balancing, bearing life, guarding and service. Compare g force and flow on the same feed, not headline speed.

What goes on an industrial centrifuge inspection checklist?+

Bowl diameter and speed against the table, balancing report serial, lid interlock, overspeed trip, vibration at speed, wetted-part certificates and a run on your own feed.

What CE documentation does an industrial centrifuge need?+

A Declaration of Conformity for that serial number with a technical file behind it, under machinery, low voltage and EMC rules, plus ATEX where solvents are used.

Who is the EU importer of an industrial centrifuge?+

The business placing it on the EU market, usually the direct buyer. Your name goes on the machine or papers, and you verify the conformity file.
